Basic Info.
Model NO.
AB Series Planetary Gearbox
Step
Single-Step
Weight
1.3
Ratio
3-100
Rated Input Speed
5000rpm
Maxium Input Speed
10000rpm
dB
<56
Gearing Arrangement
Helical
Gear Style
Planetary Gear Arrangement
Housing Material
Aluminum Casing
Product Name
Planetary Gearbox
Customized Support
OEM
Applicable Industries
Manufacturing Plant, Food & Beverage Factory, Prin
Transport Package
Wood Case
Specification
AB60
Trademark
HUAKE
Origin
China
HS Code
8501320000
Production Capacity
5000/Year
Product Description
Planetary Gearbox AB Series 42 60 90 115 142 180 220 Square Flange Helical Bevel Planetary Transmission Gearboxes Servo Motor
Product Overview:
Precision planetary gear reducer is another name for planetary gear reducer in the industry. Its main transmission structure is planetary gear, sun gear and inner gear ring.
Compared with other gear reducers, precision planetary gear reducers have the characteristics of high rigidity, high precision (single stage can achieve less than 1 point), high transmission efficiency (single stage can achieve 97% - 98%), high torque/volume ratio, lifelong maintenance-free, etc. Most of them are installed on stepper motor and servo motor to reduce speed, improve torque and match inertia.
Compared with other gear reducers, precision planetary gear reducers have the characteristics of high rigidity, high precision (single stage can achieve less than 1 point), high transmission efficiency (single stage can achieve 97% - 98%), high torque/volume ratio, lifelong maintenance-free, etc. Most of them are installed on stepper motor and servo motor to reduce speed, improve torque and match inertia.
SERIES: AB/ ABR/ AD/ADS/ ADR/ AF/ AFR/ AFX/ AFXR/ AE/ AER/ AE/ AERS
SERIES: PEII/ PEIIR/ PGII/ PGIIR/ PAII/ PAIIR/ PSII/ PSIIR/ PD/ PDR/ PL/ PLR
APPLICATION
AB-series reducer features:
1. Helical gear design The reduction mechanism adopts the helical gear design, and its tooth shape meshing rate is more than twice that of the general spur gear, and has the characteristics of smooth operation, low noise, high output torque and low backlash
2. Collet type locking mechanism The connection between the input end and the motor adopts a collet-type locking mechanism and undergoes dynamic balance analysis to ensure the concentricity of the joint interface and zero-backlash power transmission at high input speeds3. Modular design of motor connection board The unique modular design of the motor connecting plate and shaft is suitable for any brand and type of servo motor;
4. Efficient surface treatment technology The surface of the gearbox is treated with electroless nickel, and the connecting plate of the motor is treated with black anodic treatment to improve the environmental tolerance and corrosion resistance
5. One-piece gearbox body The gearbox and the inner ring gear adopt an integrated design, with compact structure, high precision and large output torque
6. Accurate concentricity of gear bar The sun gear made of the whole gear bar has strong rigidity and accurate concentricity
7. Solid, Single piece sun gear construction obtains precise concentricity with increased strength and rigidity. 8.Precision taper roller bearing support to increases radial and axial loading capacity.
7. Solid, Single piece sun gear construction obtains precise concentricity with increased strength and rigidity. 8.Precision taper roller bearing support to increases radial and axial loading capacity.
SERIES: AB/ ABR/ AD/ADS/ ADR/ AF/ AFR/ AFX/ AFXR/ AE/ AER/ AE/ AERS
PLF series, PLE series, ZPLF series, ZPLE series, AB series, ABR series and many other models are available.
Planetary Gearbox AB Series 42 60 90 115 142 180 220 Square Flange Helical Bevel Planetary Transmission Gearboxes Servo Motor
Advantages of the planetary gearbox:
Low backlash
High Efficiency
High Torque
High Input Speed
High Stability
High Reduction Ratio
| Name | High Precision Planetary Gearbox |
| Model | AB042, AB060, AB060A, AB090A, AB115, AB142, AB180, AB220 |
| Gearing Arrangement | Planetary |
| Effeiency withfull load | ≥97 |
| Backlash | ≤5 |
| Weight | 0.5~48kg |
| Gear Type | Helical Gear |
| Gear stages | 1 stage, 2 stage |
| Rated Torque | 14N.m-2000N.m |
| Gear Ratio One-stage | 3, 4, 5, 6, 7, 8, 9, 10 |
| Gear Ratio Two-stage | 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90, 100 |
| Mounting Position | Horizontal (foot mounted) or Vertical (flange mounted) |
| Usage | stepper motor, servo motor, AC motor, DC motor, etc |
