Basic Info.
Model NO.
iHSS42-24-05
Excitation Mode
Compound
Function
Run
Casing Protection
Protection Type
Number of Poles
8
Structure and Working Principle
Brushless
Certification
ISO9001, CCC, CE, RoHS
Brand
Jkong Motor
Current /Phase
1.2A
Holding Torque
0.48n.M
Motor Length
76mm
Transport Package
Carton
Specification
0.65kg
Trademark
jkong motor
Origin
Jiangsu, China
HS Code
8501310000
Production Capacity
50000piece/Month
Product Description
Integrated closed-loop servo stepper motor IHSS42-24-05
Brand: Jkongmotor
* Integrated compact size for saving mounting space
* Without losing step, High accuracy in positioning
* 100% rated output torque
* Variable current control technology, High current efficiency
* Small vibration, Smooth and reliable moving at low speed
* Accelerate and decelerate control inside, Great improvement in smoothness of starting or stopping the motor
* User-defined micro steps
* No adjustment in general applications
* Over current, over voltage and over position error protection
* Green light means running while red light means protection or off line
Specification
Other products:
Our Company offers three major series of products:Hybrid Stepper motors, Brushless Dc motor and Dc Brush motor.
We are always continues develop new type models.If you need other kinds of parts, please don't hesitate to contact us.
Brand: Jkongmotor
Name: Integrated Close Loop Stepper Motor
Voltage: 24V
Step Angle: 1.8Degree
Current: 1.2A
Speed: 0-1500Rpm
Output Shaft: 5*24mm
Shaft Flat: 4*15mm
Frame Size: 42*42mm
Flange Dia: 22mm
Encoder: 1000Line
Model Name: iHSS42-24-05
Holding Torque: 0.48Nm
Body Length: 76mm
The Integrate Stepper Servo Motor is merged the stepper servo driver and motor together. This motor system integrates the servo control technology into the digital stepper drive perfectly. And this product adopts an optical encoder with high speed position sampling feedback of 50 μ s, once the position deviation appears, it will be fixed immediately. This product is compatible the advantages of the stepper drive and the servo drive, such as lower heat, less vibration, fast acceleration, and so on.
Features The Integrate Stepper Servo Motor is merged the stepper servo driver and motor together. This motor system integrates the servo control technology into the digital stepper drive perfectly. And this product adopts an optical encoder with high speed position sampling feedback of 50 μ s, once the position deviation appears, it will be fixed immediately. This product is compatible the advantages of the stepper drive and the servo drive, such as lower heat, less vibration, fast acceleration, and so on.
* Integrated compact size for saving mounting space
* Without losing step, High accuracy in positioning
* 100% rated output torque
* Variable current control technology, High current efficiency
* Small vibration, Smooth and reliable moving at low speed
* Accelerate and decelerate control inside, Great improvement in smoothness of starting or stopping the motor
* User-defined micro steps
* No adjustment in general applications
* Over current, over voltage and over position error protection
* Green light means running while red light means protection or off line
Specification
| item | value |
| Warranty | 3months-1year |
| Place of Origin | China |
| Brand Name | jkongmotor |
| Model Number | iHSS42-24-05 |
| Phase | 2 |
| Type | Hybrid |
| Current / Phase | 1.2A |
| Certification | ce, ISO, RoHS |
| Product name | Integrated Close Loop Stepper Motor |
| Model name | iHSS42-24-05 |
| Voltage | 24V |
| Holding Torque | 0.48Nm |
| Step Angle | 1.8degree |
| Current | 1.2A |
| Shaft size | 5*24mm |
| D-cut size | 15mm |
| Body length | 76mm |
| Keywords | Integrated Closed Loop Stepper Motor |
Other products:
| Model Name: | Holding Torque: | Voltage: | Current: | Shaft Size: | D-cut Size: | Body Length: |
| iHSS42-24-05 | 0.48N.m | 24V | 1.2A | 5*24mm | 15mm | 76mm |
| iHSS42-24-07 | 0.7N.m | 24V | 1.2A | 5*24mm | 15mm | 88mm |
| iHSS57-36-10 | 1.2N.m | 36V | 4.0A | 8*21mm | 15mm | 108mm |
| iHSS57-36-20 | 2N.m | 36V | 5.0A | 8*21mm | 15mm | 127mm |
| iHSS60-36-30 | 3N.m | 60V | 5.0A | 8*31mm | 25mm | 117mm |
| iHSS86-60-45 | 4.5N.m | 60V | 6.0A | 14*38mm | 73mm | 121mm |
| iHSS86-80-85 | 8.5N.m | 80V | 6.0A | 8*21mm | 73mm | 141mm |
Our Company offers three major series of products:Hybrid Stepper motors, Brushless Dc motor and Dc Brush motor.
We are always continues develop new type models.If you need other kinds of parts, please don't hesitate to contact us.
