China low price 1-4axis G-code program motor controller for stepper motor or servo motor

The system of CM45L is stable and reliable, with a pulse frequency of 400K, 4 feed shafts, 1 simulated spindle and 2ms high-speed interpolation, which improves the machining speed, precision and surface quality of the parts.Adopt G code programming mode, USB interface, support USB disk file operation.

Mai function:

Four-axis control of X, Y, Z and C

2ms interpolation cycle

The output pulse frequency of linear interpolation on one axis is 400K

The frequency of the output pulse with arc interpolation is 300K

Quad-axis linear interpolation output pulse frequency: 350K

Ac 1 channel 0V~10V analog voltage output, support spindle control, can connect inverter or servo

Support Chinese and English language display, by parameter selection

USB interface, support USB disk file and picture import

The input of one way handwheel supports manual 1

Student 16 point universal input /8 point universal output

It has the function of electrical memory loss

The special machine interface provides customized services for special functions of customers

 Technical Index:

Number of control shaft:

Axle number: 1~4 axis (X, Y, Z, C)

The number of axes involved: X, Y, Z and C axes can be used for linear interpolation, while X and Y axes can be used for circular interpolation

The feed axis function:

Unity minimum data unit: 0.001 (unit: s, mm, cycles, degrees)

The largest data size is: plus or minus 999.999

The fast moving speed of the unity axis: when the pulse equivalent is 0.001mm, the maximum speed is 24m/min

The fast moving speed of the four axes is: when the pulse equivalent is 0.001mm, the maximum speed is 21m/min

The rotational arc movement velocity is: when the pulse equivalent is 0.001mm, up to 18m/min

Dynamic speed multiplier: 10%~200% adjustable, short press 'high' and 'low' button rate increment is 1%, long press 'high'

The rate of increase is 10%

The stallion method is linear interpolation and circular interpolation

The starting speed, termination speed and acceleration and deceleration time of the stallion deceleration are set by parameters

Spindle function:

Cycle 1 circuit 0V~10V analog voltage output, support spindle control, can connect inverter or servo drive

The rotational spindle speed is given by the S code and the speed range is 0r/min~99999r/min

The principal axis direction: can be specified by the M code

Fraud reverse clearance compensation

Experimental data acquisition display interface

A color liquid crystal screen with a resolution of 320*240

The scans are conducted in two languages, Chinese and English

Operation management:

Fraud automatic: automatic, one-step execution

Overhaul manual: motor forward and reverse rotation, return procedure zero, manual output, hand pulse

The program is new, edited, deleted, read in, and modified

Aspect parameters: control parameters, speed parameters, recovery factory values, user or vendor login, password changes, version changes

Charges: external start-up, external suspension, alarm, emergency stop, positive and negative limits, output, system self-check, etc

A picture or program that enters a usb disk

Throughout the cycle zero: X,Y,Z, and C axis mechanical cycle zero

SQL program editing

Overhaul program capacity: maximum program line 1000 lines, up to 99 program files

Aspect editing function: the program checks, modifies, and deletes

Student: this is just another one

Stalu disk file or picture import

Student: current memory function

The running coordinate and number of units remain unchanged and not reset

Student loan security function

Fraud alarm input, urgent stop input

The positive and negative limits of the overhaul hardware stroke

G Code Table

Size:
