Product Description
1000w bldc motor controller 24v controller bldc hall
This controller is designed to convert commands received from an RC radio, Analog Joystick, wireless modem, PC (via RS232 ) or microcomputer into high voltage and high current output for driving one DC motors. A version with CAN bus
allows up to 127 controllers to communicate at up to 1Mbit/s on a single twisted pair.For mobile robot applications, the controller's two motor channels can either be operated independently or mixed to set the direction and rotation of a vehicle by coordinating the motion of each motor. Numerous safety features are incorporated into the controller to ensure reliable and safe operation. The controller's operation can be extensively automated and customized using Basic Language user programs.
Model KYDBL4875-1E
| Motor Type | Brushless DC |
| Max Voltage | 55VDC |
| Number of Channels | 1 |
| Direction | Forward/Reverse |
| Max Amps per Channel | 75A |
| Analog | yes |
| RS232 | yes |
| CAN Open | yes |
| RC Pulse | yes |
| Control Loop (ms) | 1 |
| Regenerative braking | yes |
| Encoder | yes |
| Dimensions | 90mm * 70mm * 35mm |
| Weight | 800g |
- Standard export carton with sponge
- Size : base on the order
- Weight : base on the order
- Detail data will be confirmed before shipping
| Pre-service | After Sales Service |
| Inquiry and Consult Support Sample testing Support View our Factory | Help instal and use the product 24 hours online problem solving |
