Control Circuit Power Supply

Single Phase AC220V

-15~+10%  50/60Hz

Main Circuit Power Supply

3/single-phase AC220V

-15~+10%

50/60Hz

Ambient

Temperature

Operation: 0~55°C     Storage: -20°C~80°C

Humidity

<90%( free from condensation)

Vibration

<0.5G(4.9m/S²⁾,10~60Hz(non-continuous operation)

Control Method

IGBT PWM sinusoidal waveform control

Control Mode

1, Position control 2,Speed control  3,Torque control 4, Position/speed control 5, Position/Torque Control 6, Speed/Torque Control 7, Internal position control 8, Internal speed control 9, Internal torque control

Control Input

1,  Servo control enable 2,  Fault clear 3,  Initial position error clear 4,  Command pulse isable 5,  CCW driver disable 6, CW driver disable 7, Control mode selection 8,zero speed clamp

Control Output

1, Servo ready 2, Servo alarm  3, Mechanical brake release  4,  Position/Speed arrival 5,  Zero-speed detection 6,  Torque limit 7,  Phase-Z output

Encoder(Speed Sensor) Feedback

2500p/r,15 resolution incremental encoder,differential output

500 p/r,15 resolution incremental encoder,differential output

Communication method

1, RS232 2, RS485

Display and operation

1, 5-bit LED display 2,  4 buttons

Brake method

Internal/External braking resistor

Cooling method

Air cooling(Heat conductive material,High speed cooling fan)

Motor model

Compatible for various type of motors (by adjusting the system parameters)

Power range

≤5KW
